Indoor/Outdoor type
| Model | RSTQ73-400 | RSTW73-400 | RSTQ99-400 | RSTW99-400 | |
|---|---|---|---|---|---|
| Storage capacity (L) | 400 | 400 | 400 | 400 | |
| Thermal efficiency | ≥98% | ≥98% | ≥98% | ≥98% | |
| Rated heat input | kcal/h | 62440 | 62440 | 85646 | 85646 |
| kW | 73 | 73 | 99 | 99 | |
| Gas consumption (m³/h) | 7.3 | 7.3 | 9.9 | 9.9 | |
| Electric power (W) | 280 | 280 | 280 | 280 | |
| Rated working pressure (Mpa) | 1.0 | 1.0 | 1.0 | 1.0 | |
| Temperature setting range (°C) | 30-80 | 30-80 | 30-80 | 30-80 | |
| Relative hot water output(L/h) | △t=25℃ | 2478 | 2478 | 3398 | 3398 |
| △t=35℃ | 1770 | 1770 | 2427 | 2427 | |
| △t=55℃ | 1126 | 1123 | 1545 | 1545 | |
| Inlet/Outlet pipe diameter | DN50 | DN50 | DN50 | DN50 | |
| Gas connection pipe diameter | DN20 | DN20 | DN20 | DN20 | |
| Safety valve diameter | DN25 | DN25 | DN25 | DN25 | |
| Drain valve diameter | DN50 | DN50 | DN50 | DN50 | |
| Air inlet diameter | Φ110 | Φ110 | Φ110 | Φ110 | |
| Flue outlet diameter | Φ110 | Φ110 | Φ110 | Φ110 | |
| Product net weight (kg) | 344 | 345 | 354 | 355 | |
| Model | Total height A (mm) | Outlet height B(mm) | Inlet height C(mm) | Furnace body diameter D(mm) | Maximum depth E(mm) |
|---|---|---|---|---|---|
| RSTQ73-400 | 2000 | 1760 | 430 | 710 | 790 |
| RSTW73-400 | 2000 | 1760 | 430 | 710 | 790 |
| RSTQ99-400 | 2000 | 1760 | 430 | 710 | 790 |
| RSTW99-400 | 2000 | 1760 | 430 | 710 | 790 |
